Steca Solarix PRS 3030
- Order number: 030401009
Steca Solarix PRS 3030
- Easy to use charge controller
- LED display
- Automatic battery voltage detection
- Full load protection
- Low self consumption
The simplicity and high performance of the Steca Solarix PRS solar charge controller make it particularly appealing. At the same time, it offers a modern design and a convenient display, all at an extremely attractive price.
Several LEDs in various colours emulate a tank display, which gives information on the battery‘s state of charge. Here, Steca’s latest algorithms are employed, resulting in optimal battery maintenance. The Solarix PRS charge controllers are equipped with an electronic fuse, thus making optimal protection possible. They operate on the serial principle, and separate the solar module from the battery in order to protect it against overcharging.
For larger projects, the charge controllers can also be equipped with special functions: e.g. with night light function and selectable charging plateau and deep-discharge protection voltages.
Product features
- Series controller
- Automatic detection of voltage
- Voltage regulation
- PWM control
- Multistage charging technology
- Current compensated load disconnection
- Automatic load reconnection
- Temperature compensation
- Common positive or negative grounding on one terminal
- Monthly maintenance charge
Electronic protection functions
- Overcharge protection
- Deep discharge protection
- Reverse polarity protection of module (≤36 V),load and battery
- Automatic electronic fuse
- Short circuit protection of load and module
- Overvoltage protection at module input
- Open circuit protection without battery
- Reverse current protection at night
- Overtemperature and overload protection
- Load disconnection on battery overvoltage
Displays
- Multifunction LED display
- Multi-coloured LED
- 5 LEDs show operating states
- for operation, state of charge, fault messages
Options
- Night light function pre-set in the factory or adjustable via Steca PA RC 100
- Parameterisation of function values via Steca PA RC 100
Certificates
- Compliant with European Standards (CE)
- RoHS compliant
- Made in Germany
- Developed in Germany
- Manufactured according to ISO 9001 and ISO 14001
| System voltage (V): | 12 / 24 |
| Own consumption (mA): | < 4 |
| Open circuit voltage solar module (V): | < 47 |
| Module current (A): | 30 |
| Load current (A): | 30 |
| Boost charge voltage (V): | 14,4 (28,8) |
| Equalisation charge (V): | 14,7 (29,4) |
| Ambient temperature (°C): | -25 - +50 |
| Protection index (IP): | 32 |
| Dimensiones (mm): | 187 / 96 / 45 |
| Weight (kg): | 0,345 |
